Introduction to OpenCV – Digital Image Processing Exercises

Figure: Color image of Lena (left); grayscale image of Lena (middle); grayscale image of Lena with modified pixel and drawn rectangle (right).

This repository contains introductory exercises for learning Digital Image Processing Course using C++ and OpenCV.

The goal of this exercise is to understand:

How images are represented in memory
How to load and convert images
How to access and modify pixels
How to create simple generated images

📚 Table of Contents

Introduction to OpenCV – Digital Image Processing Exercises

About OpenCV

We use the OpenCV library — an open-source C++ library containing many image processing and computer vision algorithms.

Key concepts:

Most functionality lives inside the cv namespace
Images are stored using the cv::Mat data type
Images are stored row by row in memory

OpenCV uses (not )

Project Overview

This exercise demonstrates how to:

Load a color image
Convert it to grayscale
Convert between data types
Read and modify pixel values
Draw a rectangle
Generate a synthetic gradient image

How Images Are Stored in Memory

An image in OpenCV (cv::Mat) is essentially:

Pointer to data + width + height + type + step size

Images are stored row-major, meaning:

The first row is stored first in memory
Then the second row
Then the third row
And so on…

Memory layout:

Row 0:  p(0,0)  p(0,1)  p(0,2)  ...  p(0,width-1)
Row 1:  p(1,0)  p(1,1)  p(1,2)  ...  p(1,width-1)
Row 2:  p(2,0)  p(2,1)  p(2,2)  ...  p(2,width-1)
...

Grayscale Memory Layout

Grayscale image type: CV_8UC1

8 bits per pixel
1 channel
Each pixel = 1 byte

Example (3×4 image):

Image:

[  10   20   30   40 ]
[  50   60   70   80 ]
[  90  100  110  120 ]

Memory layout (linear):

10 20 30 40 50 60 70 80 90 100 110 120

Access formula:

address = base + y * step + x

Where:

y = row index
x = column index
step = number of bytes per row

Color Image Memory Layout (BGR)

Color image type: CV_8UC3

8 bits per channel
3 channels per pixel
Each pixel = 3 bytes
Order =

Example pixel:

Blue = 10
Green = 20
Red = 30

Memory storage:

[10][20][30]

Example (2×2 image):

Pixel(0,0)  Pixel(0,1)
Pixel(1,0)  Pixel(1,1)

Memory layout:

B00 G00 R00  B01 G01 R01
B10 G10 R10  B11 G11 R11

Linear memory:

p(0,0)B p(0,0)G p(0,0)R
p(0,1)B p(0,1)G p(0,1)R
p(1,0)B p(1,0)G p(1,0)R
p(1,1)B p(1,1)G p(1,1)R

Once again, OpenCV uses format, not ! That’s why there’s BGR2GRAY.

Accessing Pixels Internally

When you write:

gray.at<uchar>(y, x);

OpenCV internally computes:

data + y * step + x * element_size

For:

Grayscale → element_size = 1
Color → element_size = 3

This is why using correct type (uchar, float, Vec3b) is critical.

To open an image, we use cv::imread function that returns an image that we can store in a variable. Images can be color or grayscale. Most of our algorithms will use grayscale images. The following code reads image in color and grayscale variant and stores them in two different variables.

cv::Mat src_8uc3_img = cv::imread("images/lena.png", cv::IMREAD_COLOR);
cv::Mat src_8uc1_img = cv::imread("images/lena.png", cv::IMREAD_GRAYSCALE);

Note: If you load image using cv::IMREAD_GRAYSCALE, you don’t have to deal with color conversion described below.

Naming convention

Variable	Meaning
8U	8-bit unsigned integer (uchar)
C3	3 channels (color image)
C1	1 channel (grayscale image)

That means:

8UC3 → 8-bit, unsigned, 3-channel (color)

8UC1 → 8-bit, unsigned, 1-channel (grayscale)

Color Conversion

We can convert a color image to grayscale using:

cv::cvtColor(src_8uc3_img, gray_8uc1_img, cv::COLOR_BGR2GRAY);

And again, OpenCV uses format, not ! That’s why there’s BGR2GRAY.

We just converted color image src_8uc3_img to empty image gray_8uc1_img (you can create an empty image by declaring a variable, for example, as: cv::Mat gray_8uc1_img).

Image Data Types

When we load an image from a file, each pixel is represented using 8 bits of information (unsigned char in C++ that we can refer as uchar). Pixel values are in range 0 - 255. In grayscale image, we have one uchar per pixel. In color image, we have three uchars per pixel forming traditional RGB pixels (as we’ve seen OpenCV uses BGR format). However, for some image processing operations, it is better to represent image using values in range 0.0 - 1.0. Such values have to stored in real value data type. For our use, it’ll be completely sufficient to use float data type for such representation. To convert a grayscale image from 8 bits (uchar)representation to 32 bits (float) representation we use convertTo method of cv::Mat variable. The parameters of the method are:

output image
output data type
conversion scale

By default:

Pixel type: uchar
Range: 0-255

For some algorithms, it is better to use floating point values:

float
Range: 0.0-1.0

The method may be used as follows

gray_8uc1_img.convertTo(gray_32fc1_img, CV_32FC1, 1.0 / 255.0);

Explanation:

Parameter	Meaning
`gray_32fc1_img`	Output image
`CV_32FC1`	32-bit float, 1 channel
`1.0 / 255.0`	Scaling factor

Accessing Pixels

Since the main aim of this course is to implement image processing algorithms, we’ll need to access pixels of an image. To do so, we’ll us at method of the cv::Mat data type. This method is templated (it needs a type specifier in angle brackets before arguments).

Use the templated at<> method:

at<Type>(int y, int x)

Example:

uchar p1 = gray_8uc1_img.at<uchar>(y, x);
float p2 = gray_32fc1_img.at<float>(y, x);
cv::Vec3b p3 = src_8uc3_img.at<cv::Vec3b>(y, x);

Accessing color channels in p3:

p3[0]  // Blue
p3[1]  // Green
p3[2]  // Red

Print values of pixels:

printf( "p1 = %d\n", p1 );
printf( "p2 = %f\n", p2 );
printf( "p3[ 0 ] = %d, p3[ 1 ] = %d, p3[ 2 ] = %d\n", p3[ 0 ], p3[ 1 ], p3[ 2 ] );

We’re assigning a grayscale value (brightness) to the uchar variable p1. gray_8uc1_img has brightness values represented using 8 bits. As you can see, type specifier of at method is set to uchar. It’s followed by y, and x variables that specify, at which position to read pixel value. The same procedure is done in the case of gray_32fc1_img image, which uses 32 bits representation of brightness values. The only difference is that we use float instead of uchar data type. To access color pixels in src_8uc3_img, we need to use cv::Vec3b. This type holds three values (BGR) at once. To access each color value, we use [] operator as is used in the above example.

Modifying Pixels

Another important operation with image pixels is, of course, setting a new pixel brightness. This is done again using at method. The only difference from the read operation is that we assign a new value to the method.

To change a pixel value:

gray_8uc1_img.at<uchar>(y, x) = 0;  // set to black

We’ll use this notation very often.

Creating a Gradient Image

When implementing image processing algorithms, you’ll quite often need to go through all image pixels and perform some operation with brightness values. To access all pixels, we usually use two nested for loops to iterate over all rows and in each row to iterate over all columns. As an example, we’ll create a gradient image. First, we crate a new image named gradient_8uc1_img with 50 rows and 256 columns and with CV_8UC1 pixel data type. This means that image will use 8 bits as data representation (uchar) and one channel, so it’s essentially a grayscale image. Then we iterate over all pixels and assign brightness value according to the column number.

We generate a synthetic image:

Width: 256 pixels
Height: 50 pixels
Type: CV_8UC1

cv::Mat gradient_8uc1_img(50, 256, CV_8UC1);

for (int y = 0; y < gradient_8uc1_img.rows; y++) {
    for (int x = 0; x < gradient_8uc1_img.cols; x++) {
        gradient_8uc1_img.at<uchar>(y, x) = x;
    }
}

Result image after calling cv::imshow( "Gradient 8uc1", gradient_8uc1_img );:

This creates a horizontal gradient from black (0) to white (255).

Full Example Code

#include <stdio.h>
#include <opencv2/opencv.hpp>

int main( int argc, char *argv[] )
{
    cv::Mat src_8uc3_img = cv::imread( "images/lena.png", cv::IMREAD_COLOR ); // load color image from file system into Mat variable, this will be loaded using 8 bits (uchar)

    // declare variable to hold grayscale version of img variable, gray levels wil be represented using 8 bits (uchar)
    cv::Mat gray_8uc1_img;
    // declare variable to hold grayscale version of img variable, gray levels wil be represented using 32 bits (float)
    cv::Mat gray_32fc1_img;

    cv::cvtColor( src_8uc3_img, gray_8uc1_img, cv::COLOR_BGR2GRAY ); // convert input color image to grayscale one, CV_BGR2GRAY specifies direction of conversion
    gray_8uc1_img.convertTo( gray_32fc1_img, CV_32FC1, 1.0 / 255.0 ); // convert grayscale image from 8 bits to 32 bits, resulting values will be in the interval 0.0 - 1.0

    int x = 10, y = 15; // pixel coordinates

    uchar p1 = gray_8uc1_img.at<uchar>( y, x ); // read grayscale value of a pixel, image represented using 8 bits
    float p2 = gray_32fc1_img.at<float>( y, x ); // read grayscale value of a pixel, image represented using 32 bits
    cv::Vec3b p3 = src_8uc3_img.at<cv::Vec3b>( y, x ); // read color value of a pixel, image represented using 8 bits per color channel

    // print values of pixels
    printf( "p1 = %d\n", p1 );
    printf( "p2 = %f\n", p2 );
    printf( "p3[ 0 ] = %d, p3[ 1 ] = %d, p3[ 2 ] = %d\n", p3[ 0 ], p3[ 1 ], p3[ 2 ] );

    gray_8uc1_img.at<uchar>( y, x ) = 0; // set pixel value to 0 (black)

    // draw a rectangle
    cv::rectangle( gray_8uc1_img, cv::Point( 65, 84 ), cv::Point( 75, 94 ),
                   cv::Scalar( 50 ), cv::FILLED );

    // declare variable to hold gradient image with dimensions: width= 256 pixels, height= 50 pixels.
    // Gray levels wil be represented using 8 bits (uchar)
    cv::Mat gradient_8uc1_img( 50, 256, CV_8UC1 );

    // For every pixel in image, assign a brightness value according to the x coordinate.
    // This wil create a horizontal gradient.
    for ( int y = 0; y < gradient_8uc1_img.rows; y++ ) {
        for ( int x = 0; x < gradient_8uc1_img.cols; x++ ) {
            gradient_8uc1_img.at<uchar>( y, x ) = x;
        }
    }

    // diplay images
    cv::imshow( "Gradient 8uc1", gradient_8uc1_img );
    cv::imshow( "Lena gray 8uc1", gray_8uc1_img );
    cv::imshow( "Lena gray 32fc1", gray_32fc1_img );

    cv::waitKey( 0 ); // wait until keypressed

    return 0;
}

How to Build and Run

Option 1 - Using `g++` on command line

$ g++ main.cpp -o app `pkg-config --cflags --libs opencv4`
$ ./app

Option 2 - Using CMake (inluded in the template for Linux)

In Visual Studio Code, have installed CMake plugin:

$ code --install-extension ms-vscode.cpptools
$ code --install-extension ms-vscode.cmake-tools

Then run project by pressing: Shift + F5.

Or run using command line:

$ mkdir build
$ cd build
$ cmake ..
$ make
$ ./app

🎓 Learning Outcomes

After completing this exercise, you should understand:

How images are stored in memory (row-major order)
Difference between 1-channel and 3-channel images
Why OpenCV uses BGR
How cv::Mat manages memory
How pixel access translates to pointer arithmetic
The foundation of implementing custom image processing algorithms
